  #941
Old 01-21-2015, 08:42 AM
gtmule gtmule is offline

Join Date: Oct 2007
Location: Macon, GA
Posts: 507
Default

Finally done. Pardon the empty hole, I had to send the Trio Pro-pilot back for repair. I'm really happy with the layout of the equipment and switches so far.











GRT HXr, 430W, A210, GTX-327, Trio Propilot, GRT Mini-B, PSE 5000EX, 2 fuse boxes (Master buss and E-Buss), backup (alarm) battery wired to the E-buss for avionics brownout protection during startup and emergencies, dual alternators (N-D (Honda) and an SD-8) and an emergency feed from the Oddysey battery to the E-buss, for when it all goes REALLY wrong.
__________________
Macon, GA (KMCN)
RV-7, Niner Fife Victor

Last edited by gtmule : 01-21-2015 at 08:48 AM.
Reply With Quote
  #942
Old 01-22-2015, 08:10 AM
floridawing floridawing is offline

Join Date: Jan 2010
Location: Orlando, Florida
Posts: 141
Default Large HXR

Very nice, is that the 12.1 HXR?
Reply With Quote
  #943
Old 01-22-2015, 08:27 AM
terrykohler terrykohler is offline

Join Date: Jan 2005
Posts: 1,044
Default Nice Job Chuck!

Great layout. You'll probably see a few more copies of this down the road. For some of us, we could probably use an annunciator light next to the lower placard.
Terry, CFI
RV9A N323TP
Reply With Quote
  #944
Old 01-22-2015, 11:51 AM
gtmule gtmule is offline

Join Date: Oct 2007
Location: Macon, GA
Posts: 507
Default

Quote:
Originally Posted by floridawing View Post
Very nice, is that the 12.1 HXR?
Thanks! Negative, it's the 10.4, but it's stuffed into a standard height panel, because I didn't want to sacrifice any maneuvering room.

Quote:
Great layout. You'll probably see a few more copies of this down the road. For some of us, we could probably use an annunciator light next to the lower placard.
Terry, CFI
RV9A N323TP
Thanks. Maybe I should print another one in yellow or red and put it above the HXr...
__________________
Macon, GA (KMCN)
RV-7, Niner Fife Victor
Reply With Quote
  #945
Old 01-22-2015, 01:13 PM
Zero4Zulu Zero4Zulu is offline

Join Date: Nov 2008
Location: Scio,Oregon
Posts: 294
Default

I just have to ask... Is that cabin heat cable from a vintage Ford?
__________________
Steve S.
Rebuilt RV6A Flying!
Scio, OR
EAA Ch. 292
Reply With Quote
  #946
Old 01-22-2015, 01:49 PM
gtmule gtmule is offline

Join Date: Oct 2007
Location: Macon, GA
Posts: 507
Default

Quote:
Originally Posted by Zero4Zulu View Post
I just have to ask... Is that cabin heat cable from a vintage Ford?
I think it's from a cherokee 180. I didn't build the plane, but that's what the engine was on, I got rid of all the old cherokee switches and breakers when I did the panel, but figured I'd leave the cabin heat knob for posterity.
__________________
Macon, GA (KMCN)
RV-7, Niner Fife Victor
Reply With Quote
  #947
Old 01-26-2015, 10:41 AM
sjarrell sjarrell is offline

Join Date: Jul 2010
Location: Hendersonville, NC
Posts: 169
Default Panel by Vic Syracuse (Baseleg Aviation)

Here is my panel that Vic Syracuse just finished for me. Great job Vic! There's another post here that shows the before and after shots.

__________________
Steve Jarrell
Building RV-14A QB "Freedom"
N614US (June 14 - Flag Day)
Dues Paid - Gladly!
Reply With Quote
  #948
Old 02-01-2015, 06:56 PM
MTBengel MTBengel is offline

Join Date: Feb 2011
Location: Nashville, TN
Posts: 53
Default

Quote:
Originally Posted by Jamie View Post
Mark, that panel is beautiful. Congrats.

Does that arrangement give you full forward motion for the stick?
Jamie - Sorry to be so long answering your question... the sticks hit the stop about 1" from the panel. - Mark
__________________
Mark
RV7 - under construction
Reply With Quote
  #949
Old 02-03-2015, 01:38 PM
larrynew's Avatar
larrynew larrynew is offline

Join Date: Oct 2007
Location: In New Braunfels, ist das Leben schön!
Posts: 919
Default

I think I'm done with the panel except for a pesky PWM switch that keeps breaking. All hand cut, painted,
labeled and wired myself. Moving the fuselage to the hanger this week to meet the rest of the parts for final assembly.

__________________
Larry New
RV-7A - Built, flew 950+ hrs, sold
RV-10 - Built, flying 250+ hrs
RV-12iS - All kits ordered!
VAF on Annual Autopay
Reply With Quote
  #950
Old 02-03-2015, 03:51 PM
rightrudder rightrudder is offline

Join Date: Mar 2014
Location: Laguna Hills, CA
Posts: 1,853
Default

Looks good, Larry! Very tidy.
__________________
Doug
RV-9A "slider"--sold in July 2021
Flew to Osh in 2017, 2018 & 2019!
Donation made for 2021
You haven't seen a tree until you've seen its shadow from the sky -- Amelia Earhart
Reply With Quote
